General Description
The evaluation of critical process parameters and raw materials such as calcined petroleum coke, binders, recycled materials, and additives on bench scale is essential to conduct research and development projects for continuous improvement in anode manufacturing. The production of anodes at the bench scale under controlled conditions is a fast, reliable, and cost effective approach to assess the quality of raw materials and optimize process parameters, avoiding the expensive exercise of full-scale trials.
Key components of the RDC-161 setup include:
- Preheating oven: used to bring the dry aggregate to a target temperature before mixing.
- Eirich mixer: an intensive impeller mixer equipped with temperature control to ensure consistent, homogeneous paste production.
- Forming Press: designed for shaping green bench scale anodes with a standardized 50 mm diameter and approximately 100 mm length.
Depending on the application, additional equipment is potentially needed to prepare the dry aggregate, bake the green electrodes, and test their properties.
Technical Information
Function
Production of Bench Scale Electrodes
Maximum Temperature
180°C
Sample
Electrode paste up to 8 kg
Installation
Floor standing under fume hood
Dimensions (LxWxH)
Furnace : 125 x 82 x 180 mm
Mixer : 162 x 82 x 210 mm
Press : 122 x 82 x 220 mm
Weight
Furnace : 260 kg
Mixer : 510 kg
Press : 550 kg
Electrical Property
Furnace 400 : V 3/N/PE, 50 Hz
3.4 kW, 8.5 A
3.4 kW, 8.5 A
Mixer 400 V : 3/N/PE, 50 Hz
7.1 kW, 18 A
7.1 kW, 18 A
Press 400 V : 3/N/PE, 50 Hz
1.5 kW, 4 A
1.5 kW, 4 A
Database Connection
No
